WiPy 2.0

349 kr

WiPy 2.0, The tiny Micro Python enabled WiFi & Bluetooth IoT development platform. With a 1KM WiFi range, state of the art Espressif ESP32 chipset and dual processor, the WiPy is all about taking the Internet of Things to the next level.

Description

WiPy 2.0, The tiny Micro Python enabled WiFi & Bluetooth IoT development platform. With a 1KM WiFi range, state of the art Espressif ESP32 chipset and dual processor, the WiPy is all about taking the Internet of Things to the next level.

Features

Basic

  • Powerful CPU, BLE and state of the art WiFi radio

  • 1KM Wi Range

  • MicroPython enabled, the Linux of IoT for fast deployment

  • Fits in a standard breadboard (with headers)

  • Ultra-low power usage: a fraction compared to other connected micro controllers

  • Hardware floating point acceleration

  • Python multi-threading

  • 2 x UART, 2 x SPI, I2C, I2S, micro SD card

  • DMA on all peripherals

Processing

  • Espressif ESP32 chipset

  • Dual processor + WiFi radio System on Chip.

  • Network processor handles the WiFi connectivity and the IPv6 stack.

  • Main processor is entirely free to run the user application.

  • An extra ULP-coprocessor that can monitor GPIOs, the ADC channels and control most of the internal peripherals during deep-sleep mode while only consuming 25uA.

Mechanical

Technical details

Dimensions0mm x0mm x0mm
WeightG.W 28g
BatteryExclude
Input3.3V – 5.5V
RTC32KHz
WIFI802.11b/g/n 16 mbps
BluetoothLow energy and classic
Hash / encryptionSHA, MD5, DES, AES
AM512KB
External flash4MB
Analog channels8x12 bit ADCs
Timers4x16 bit with PWM and input capture
GPIOUp to 24
Security and CertificationsSSL/TLS support; WPA Enterprise security; FCC – 2AJMTWIPY2R; CE 0700

Part List

WiPy 2.01

ECCN/HTS

ECCN5A002.a.1
HSCODE8517709000
UPC841454120506
