Raspberry Pi Zero W with Basic Components A

Raspberry Pi Zero W (built-in WiFi) Development Kit Type A, Basic Components

Overview

This development kit includes the Raspberry Pi Zero W (built-in WiFi), and some most basic components you may need to get going with your Pi Zero: Mini HDMI to HDMI Adapter, Micro USB OTG Cable, and 2×20-pin 2.54 male/female pin header strips.

Raspberry Pi Zero W Features

• Broadcom BCM2835
  • 1GHz ARM11 single-core processor
• 512MB RAM
• Added wireless connectivity
  • 802.11 b/g/n wireless LAN
  • Bluetooth 4.1
  • Bluetooth Low Energy (BLE)
• Micro SD card slot
• Mini-HDMI port (1080p60 video output)
• Micro-USB power
• Micro-USB OTG port
• 40PIN unpopulated GPIO header (compatible with A+/B+/2B/3B)
• CSI camera connector
• Composite video header
• Composite reset header
• Dimension: 65mm x 30mm x 5mm

Shipping list

Weight: 0.038 kg

1. Raspberry Pi Zero W x1
2. Mini HDMI to HDMI Adapter x1
3. Micro USB OTG Cable x1
4. 2x20-pin 2.54 male pin header strip x1
5. 2x20-pin 2.54 female pin header strip x1
