Raspberry Pi 5 – 16 GB

  • 173.56 EUR

The Raspberry Pi 5 offers unparalleled performance improvements, powered by a 64-bit quad-core Arm Cortex-A76 processor clocked at 2.4GHz. It delivers 2-3x the

I lager.
Article Number: 1360
Share
  • Information

The Raspberry Pi 5 offers unparalleled performance improvements, powered by a 64-bit quad-core Arm Cortex-A76 processor clocked at 2.4GHz. It delivers 2-3x the CPU performance of its predecessor, the Raspberry Pi 4. Equipped with an 800MHz VideoCore VII GPU, it features dual 4Kp60 HDMI outputs, advanced camera support via a redesigned Image Signal Processor (ISP), and a smooth desktop experience for both consumer and industrial applications.

For the first time, the Raspberry Pi 5 integrates in-house silicon design, featuring the RP1 “southbridge”, which significantly enhances I/O capabilities. This upgrade includes doubled USB bandwidth, faster SD card performance, and support for PCI Express 2.0, allowing high-speed peripheral connections. Dual 1.5 Gbps 4-lane MIPI interfaces provide flexibility for cameras and displays, offering increased bandwidth compared to previous models.

Key Specifications and Features

Processor

  • Broadcom BCM2712: 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU
    • Cryptography extensions
    • 512KB per-core L2 cache and 2MB shared L3 cache

Graphics and Video

  • VideoCore VII GPU:
    • Supports OpenGL ES 3.1 and Vulkan 1.2
    • Dual 4Kp60 HDMI® outputs with HDR support
    • 4Kp60 HEVC decoder

Memory

  • LPDDR4X-4267 SDRAM
    • Available in 4GB, 8GB, and 16GB configurations

Connectivity

  • Dual-band 802.11ac Wi-Fi®
  • Bluetooth 5.0 with BLE support
  • Gigabit Ethernet with PoE+ support (via separate PoE+ HAT)

I/O Ports

  • 2 × USB 3.0 ports (5Gbps)
  • 2 × USB 2.0 ports
  • MicroSD card slot with SDR104 high-speed mode

Camera and Display

  • 2 × 4-lane 1.5 Gbps MIPI transceivers
    • Supports any combination of up to two cameras or displays

Expansion

  • PCIe 2.0 x1 interface (requires additional M.2 HAT or adapter)

Power

  • 5V/5A DC via USB-C with Power Delivery support
  • Real-time clock (RTC) powered by an external battery
  • Standard Raspberry Pi 40-pin GPIO header

Additional Features

  • Integrated power button
  • Enhanced peripheral performance

The Raspberry Pi 5 sets a new benchmark for single-board computers, with enhanced power, flexibility, and expandability, making it a game-changer for advanced projects, embedded systems, and industrial use cases.
