LOLIN D32 Pro

  • 189 kr

LOLIN D32 Pro V2.0.0 - wifi & Bluetooth board based ESP-32 esp32 Rev1 ESP32-WROVER 16MB 8MB 4MB FLASH PSRAM MicroPython16MB FLASH:  16MBytes FLASH,8MBy

I lager.
Lagersaldo: 4
Artikelnummer: SKU196
Dela

LOLIN D32 Pro V2.0.0 - wifi & Bluetooth board based ESP-32 esp32 Rev1 ESP32-WROVER 16MB 8MB 4MB FLASH PSRAM MicroPython

  • 16MB FLASH:  16MBytes FLASH,8MBytes PSRAM(*only 4MB can be used directly by software: Arduino, MicroPython)
  • 4MB FLASH:  4MBytes FLASH,4MBytes PSRAM
  • 16MB FLASH(LED):  16MBytes FLASH,8MBytes PSRAM(*only 4MB can be used directly by software: Arduino, MicroPython), the red LED will fast flashing when the battery is not connected.

Features

  • WIFI

  • Bluetooth

  • 16MB/4MB Flash

  • 8MB (*only 4MB can be used directly by software: Arduino, MicroPython) /4MB PSRAM

  • Lithium battery interface, 500mA Max charging current

  • LOLIN I2C port

  • LOLIN TFT port

  • TF (Micro SD) Card slot, support SPI mode.

  • Compatible with Arduino, MicroPython

  • Default firmware: lastest MicroPython


Wemos LOLIN D32 Pro är ett Wifi och Bluetooth utvecklingsbord baserad på ESP32-WROVER-modulen som har en inbyggd 4 MByte SPI RAM. De viktigaste funktionerna i bordet är

  • Micro-SD-kortgränssnitt
  • TFT-skärmgränssnitt
  • SPI RAM 4 MByte

Features

  • Espressif official ESP32-WROVER module
  • Lastest ESP32 Version: REV1
  • 4MB FLASH
  • 4MB PSRAM
  • Lithium battery interface, 500mA Max charging current
  • LOLIN I2C port
  • LOLIN TFT port
  • TF (Micro SD) Card slot, support SPI mode.
  • Compatible with Arduino, MicroPython
  • Default firmware: lastest MicroPython

Technical specs

Microcontroller
ESP-32
Board Power Supply (USB)
5V
Supported Batteries
Lipo Battery 3.7V
Operating Voltage
3.3V
Digital I/O Pins
22
Analog Input Pins
6 (VP, VN, 32, 33, 34, 35)
Analog Output Pins
2 (25, 26)
LED_BUILTIN
5
Clock Speed(Max)
240Mhz
Flash
4M bytes
Length
65mm
Width
25.4mm
Weight
7.5g


More information LOLIN homepage
