Slamtec Mapper M1M1 ToF Laser Scanner Kit - 20M Range

I lager.

2 649 kr

Pre-order

We can deliver this product upon request within one week.

SLAMTEC has released the Slamtec Mapper M1M1 ToF laser mapping sensor. It is more than a laser range scanner, the M1M1 features high-quality mapping and real-time localization or navigation function. Which means it can easily map for your home or office. Actually, it supports both indoors and outdoors mapping, supports large working scenarios over 100,000 m². Such High-performance thanks to the SLAMTEC third-generation high-performance SLAM engine. On top of that, SLAMTEC M1M1 is quite easy to use, it comes with SLAMTEC full cross-platform SDK and tools for both mobile phones and PC. Get one now and make your own map, it pretty cool!




Plug and play, without any external dependency. It is suitable to be applied in application fields like robot localization and navigation, environment surveying and mapping and etc.


Large Scenarios and High-quality Mapping

Slamtec Mapper adopts SLAMTEC third-generation high-performance SLAM graph optimization engine and SharpEdge™ mapping technology to realize a high accurate thousand-square-meter map building and real-time localization, and it can actively detect the closed-loop and correct map.

The mapper is an ideal choice for users to realize mapping and re-localization in various complicated scenarios and output map and localization data that meets users' expectations.

Plug and play, without any external dependence

Slamtec Mapper just needs a USB power cable to work well, without any additional support or accessories.

Tilting Compensation and Fast Moving

With built-in inertial navigation system with nine degrees of freedom, Slamtec Mapper can work properly in tilting and shaky hand-held mode and ensure an excellent map data quality. In addition, it supports to move fast with a maximum speed of 1m/s.

Indoor and Outdoor Availability

Whether in complicated indoor environment or outdoor environment with direct daylight, Slamtec Mapper shows a good performance in mapping and localization in those complicated scenarios.


Fully Compatible with ROS, Easy Data Analysis

Slamtec Mapper provides completed cross-platform SDK and tools both on phone and PC side for users to evaluate, develop and use.

Through matched ROS driver, you can integrate the generated map and localization data into ROS environment seamlessly.

More Than A Mapper

Slamtec Mapper is not only a mapper for mapping and localization, you can also use it directly as a laser range scanner. Via SDK or ROS node, you can easily put the data of the laser range scanner into the user's current system.

Built-in WIFI, Ethernet port, Easy communication

With built-in access point and station mode WiFi as well as 100M Ethernet port, you can get the real time map and localization data generated by Slamtec Mapper through designed mobile application.


Key parameters

ModelM1M1
Distance Range20m
Sample Rate7K
Max Mapping Area300m x 300m
Resolution5cm
Max Moving Speed1m/s
Max Rotate SpeedTBD
Re-localization Accuracy<0.02m
Map Optimization DurationAbout 1 hour
Slope Angle±3°
Data Refresh Rate8Hz


SHIPPING LIST

  • SLAMTEC MAPPER M1M1-360°Laser Mapping Sensor TOF 20

Developing resources
