ARM Debugger Programmer

JTAG/SWD Debugger Programmer with Micro USB Interface

Overview

ARM Debugger is a debugger and programmer which supports the most popular ARM core MCUs including : ARM7/9/11, Cortex-M0/M3/M4, etc.

Specifications

• Onboard self-recovery fuse, prevent any damage from short circuit
• 3.3V output, make it easy to debug/program the code
• Universal Micro USB interface
• Protected by heat-shrink tube
• Unique ID, supports multi devices to work together at the same time

Functionality and Performance

• Debugging
  • Supports full-speed running, single step, breakpoints and so on. Check IO status, variable, etc.
  • Quick response through the USB2.0 interface
• Programming
  • Programs FLASH ROM, EEPROM, AFR, etc.
  • High speed SWD programming through the USB2.0 interface

Supported Software

• Keil MDK-ARM
• IAR EWARM
• J-Flash ARM
• CoIDE
• mikroC PRO for ARM
• nRFgo Studio (Version 1.15 OR before)

Supported MCUs

All the MCUs with SWD interface of the following cores : ARM7, ARM9, ARM11, Cortex-M0, Cortex-M3, Cortex-M4

Development Resources

Wiki

Weight: 0.058 kg

1. ARM Debugger unit x 1
2. USB Type A Plug to Micro B Plug Cable x 1
3. 4-pin SWD wire x 1
4. 4-pin jumper wire (2.0 to 2.54 pitch) x 1
