9inch Capacitive Touch Monitor, 2560×1600 2K Resolution, IPS, Mini HDMI, Fully Laminated

I lager.
Antal: 1

1 999 kr

Artikelnummer: 813


9inch Capacitive Touch Monitor, Mini HDMI Port, 2560×1600 2K Resolution, IPS Screen, Fully Laminated Toughened Glass Panel, Various Systems & Devices Support Including Raspberry Pi, Jetson Nano, PC...

9" 2K Touch Monitor

Size  9"

Resolution 2560×1600

Display Port Mini HDMI

Display Panel IPS

Viewing Angle  178°

Touch Type Capacitive

TouchPoints 10-Points

Touch Port USB

Touch Panel Toughened Glass

Touch Panel Tech Fully Laminated

Sound Hi-Fi Speaker

Audio Output  3.5mm Jack

Enclosure CNC Process Alloy

Device & System Support


Raspberry Pi

Supports Raspbian, 10-points touch, driver, free
Supports Ubuntu / Kali / WIN10 IoT, single-point touch, driver free
Supports Retropie, driver free

Supports all versions of Raspberry Pi

Jetson Nano

Supports Ubuntu, single-point touch, driver, free


Supports Windows 10 / 8.1 / 8 / 7, 10-points touch, driver free

Connection Examples

Working With Raspberry Pi 4

Working With Raspberry Pi 3B+

Working With Raspberry Pi Zero W

Working With AI Computer Jetson Nano

Working With Mini PC

Display Panel

IPS Panel, Up To 70% NTSC Color Gamut, Up To 350nit Brightness

2K High Resolution

2560×1600 High Resolution, Presents Distinct & Ddetailed Picture

Touch Control


1) up to 10-points touch, depending on the operating system. 2) up to 6H hardness toughened glass panel. 3) fully laminated screen, better display experience, dust-proof.

Audio Feature


Appearance And Dimensions

Resources & Services

Wiki: www.waveshare.com/wiki/9inch_2560x1600_Monitor

Shipping list

Weight: 0.621 kg

  1. 9inch 2560x1600 Monitor
  2. Mini HDMI to Micro HDMI cable
  3. Mini HDMI to HDMI cable
  4. USB-A to Micro-B cable
  5. Triangular stand
