IMX477-160 12.3MP Camera, 160° FOV, Applicable For Jetson Nano / Compute Module

  • 649 kr

IMX477-160 12.3MP Camera, 160° FOV, Applicable For Jetson Nano / Compute Module.12.3MP CAMERA MODULEIMX477 Sensor, 12.3MP, Applicable For Jetson Nano / Compute

Produkten är tyvärr slut i lager. :(

Artikelnummer: 953
Dela
  • Information

IMX477-160 12.3MP Camera, 160° FOV, Applicable For Jetson Nano / Compute Module.

12.3MP CAMERA MODULE

IMX477 Sensor, 12.3MP, Applicable For Jetson Nano / Compute Module

Specifications
SENSORModelSony IMX477
Resolution12.3MP, 4056 × 3040
CMOS diagonal length7.9mm
pixel size1.55µm (H) × 1.55µm (V)
CAMERAAperture (F)2.2
Focal length (BFL)5.52
Field of view (FOV)160°(D) 118°(H) 87°(V)
Distortion<16%
OPERATING VOLTAGE3.3V
APPLICATIONSsuitable for AI applications like: facial recognition, road mark recognition, license plate number recognition, and so on.
Working With Jetson Nano

Jetson Nano Developer Kit B01 (Left) And Jetson Nano 2GB Developer Kit (Right)

*Jetson Nano is NOT included, and specific driver is required for the Jetson Nano to use the IMX477 camera module.

Working With Raspberry Pi Compute Module

Compute Module 4 + IO Board (Left) And Compute Module 3 + IO Board (Right)

*CM4, CM3, IO Board, and the yellow FFC are NOT included.


Wiki: IMX477-160_12.3MP_Camera


Shipping list

Weight: 0.012 kg

  1. IMX477-160 12.3MP Camera (with FFC) x1
