Game HAT for Raspberry Pi

  • 499 kr

This Game HAT will turn your Raspberry Pi into a classic game console in a second, recalls you all the gaming pleasures in the memory.Game HAT Features3.5inch I

I lager.
Lagersaldo: 1
Artikelnummer: 68
Dela

This Game HAT will turn your Raspberry Pi into a classic game console in a second, recalls you all the gaming pleasures in the memory.

Game HAT Features

  • 3.5inch IPS screen, 480×320 resolution
  • 60 frame experience, smoothly display, no more frame loss
  • Compatible with Raspberry Pi A+/B+/2B/3B/3B+ (Raspberry Pi Zero/Zero W/Zero WH requires another HDMI cable)
  • Integrates battery charge circuitry, powered from a 18650 lithium battery (NOT included), plays anywhere anytime
  • Battery capacity indicator
  • Onboard speaker and earphone jack, listen to the familiar BGM from the old days

Keys Introduction

Game HAT keys introduction

  • Game function keys vary according to specific game
  • Start + Select to exit current game
  • Menu, Up/Left, Down/Right, Exit, this four keys on the bottom allow to adjust screen brightness/contrast, volume, etc.

Dimensions

Game HAT dimensions

Development Resources

Wiki : www.waveshare.com/wiki/Game_HAT

Shipping list

Weight: 0.212 kg

Note: the Raspberry Pi and 18650 battery in the photo are NOT included.

  1. Game HAT x1
  2. Acrylic case x1
  3. HDMI connector x1
  4. RPi screws pack x1
